Energy Storage Battery
video
Energy Storage Battery

Energy Storage Battery

Benwei Container Battery
This product is composed of high quality lithium iron phosphate core (series-parallel connection) and advanced BMS management system. It can be used as independent DC power supply or as "basic unit" to form a variety of energy storage lithium battery power supply systems. It has high reliability and long life. Products developed for applications such as power grid energy storage, industrial and commercial energy storage, home high voltage energy storage, high voltage UPS, and data room.
إرسال التحقيق
مقدمة المنتج



energy storage battery

solar power batteries

Benwei Container Battery

energy storage battery

This product is composed of high quality lithium iron phosphate core (series-parallel connection) and advanced BMS management system.                                                 It can be used as independent DC power supply or as "basic unit" to form a variety of energy storage lithium battery power supply systems. It has high reliability and long life. Products developed for applications such as power grid energy storage, industrial and commercial energy storage, home high voltage energy storage, high voltage UPS, and data room.


Product Specification:

ModelBW 220100BW 220200BW 360100BW 360200BW 384100BW 384200
Type of coreLithium iron phosphate
Rated energy(KWH)224436724080
Nominal capacity (AH)100200100200100200
Nominal voltage(VDC)220.8
358.4384
Operating voltage range(VDC)179259291420312450
Recommended Charge Voltage(VDC)242392420
Recommended discharge cutoff voltage(VDC)210342366
Standard charging current (A)508050805080
Maximum continuous charge current(A)100200100200100200
Standard discharge current (A)508050805080
Maximum continuous discharge current(A)100200100200100200
Working temperature-2065 degree
Protection levelIP20
Communication interfaceRS485/CAN two choose one
Reference Weight (Kg)3006004709405001000
Reference size(DWHmm)530650118062555018105305501810(6255502040)25305502020(6255501600)2

Detailed:

energy storage battery

Lithium ion battery have been deployed in varied places. From a small electronics battery to large energy storage and power driving batteries used in solar system, golf cart, medical equipment, electric mobility, power back up, ups and other application,  lithium iron phosphate batteries are available in all shapes and sizes. And that renders them to be the perfect option for power needs irrespective of the size of the application devices. This battery cell cyclelife is 5000 times at 80 percent DOD what we use is a smart BMS with many function here ,In the front of the battery you could see it has ON/OFF buttons ,Running light ,alarm light ,SOC light which could be show the battery capacity when you discharge and charge the battery.


solar energy storage batteriesMore

20kw solar system with battery storage

Photovoltaic Utility Scale Lithium Battery Storage

10KW 1000KW 1MWH KVA Lithium ion Energy Solar Storage System

Professional Engineer team :

Own an excellent engineer team with more than 10years' rich experiences in lithium battery RD , design the excellent battery solution for clients ! Our mechanical and electrical engineer is professional in structural , software and hardware for designing the best customized battery , which ensure our battery pack comply with most competitive cells , battery pack and BMS solutions with the advanced lithium technology .


Good Raw material supply chain : we have built a long-term business relationship with the well-known IC and battery cells companies , which ensure provoding our clients with high quality and powerful performance battery pack .
